>> Introduction
A rolling shutter door motor is an essential component of a rolling shutter door system. It is an electric motor that powers the opening and closing of the door by winding and unwinding the shutter from its drum. These motors are designed to provide reliable and efficient operation, making it easy to control the door with minimal manual effort.
The product offers 11 precise models, covering a full load range from 300KG to 1500KG. It includes two series: AC (alternating current) and DC (direct current). The maximum lifting height can reach 13 meters. It adopts a hightorque gear transmission design, ensuring smooth and quiet operation, low energy consumption, and long lifespan. It is equipped with multiple safety protection systems and supports manual emergency opening in case of power outage. It can be seamlessly linked with the OMKER E-LINKED intelligent access control system to achieve remote control via mobile APP, unified management of multiple devices, and permission level setting. Up to 50 mobile phones can be authorized.
The entire machine is designed in an integrated and compact style, making installation convenient and eliminating the need for complex renovations. A one-year whole machine warranty and lifetime online technical support are provided. Customized services for projects are supported. It is an ideal choice for automated upgrade of roller shutters in residential garages, commercial stores, factory warehouses, and commercial buildings.
Model | Power Source (V) | Rated Frequency (Hz) | Lifting Force (KG) | Output Torque (N.m) | Output Speed (r/min) | Lifting/Mass Raising Height | Rated Power (W) | Rated Current (A) | Short-team Ration (min) |
DCK-300KG-1P | 220 | 50 | 300 | 164 | 5 | 6.0 | 250 | 2.5 | 8 |
DCK-300KG-3P | 380 | 50 | 300 | 343 | 5 | 6.0 | 180 | 0.8 | 15 |
DCK-600KG-1P | 220 | 50 | 600 | 412 | 6 | 6.0 | 370 | 3.5 | 8 |
DCK-600KG-3P | 380 | 50 | 600 | 412 | 6 | 6.0 | 250 | 1.5 | 15 |
DCK-800KG-1P | 220 | 50 | 800 | 647 | 4.2 | 9.0 | 400 | 4.7 | 8 |
DCK-800KG-3P | 380 | 50 | 800 | 647 | 4.2 | 9.0 | 300 | 2.3 | 15 |
DCK-1000KG-3P | 380 | 50 | 1000 | 810 | 3.6 | 9.0 | 400 | 2.4 | 15 |
DCK-1300KG-3P | 380 | 50 | 1300 | 1050 | 4.2 | 13.0 | 600 | 3.5 | 15 |
DCK-1500KG-3P | 380 | 50 | 1500 | 1220 | 3.8 | 13.0 | 600 | 4.0 | 15 |
DCK-DC-500KG-1P | 220 | 50 | 500 | 490 | 4.8 | 6.0 | 200 | 12.0 | |
DCK-DC-600KG-1P | 220 | 50 | 600 | 588 | 4.8 | 6.0 | 250 | 12.0 |
>> Function And Features
>> FAQ
1.How does a rolling shutter door motor work?
2.What are the differences between AC motors and DC motors? How should I choose?
• AC AC motors: Mature technology, high reliability, relatively low price, suitable for most conventional applications
• DC DC motors: More energy-efficient (saving up to 30% more electricity than AC motors), quieter, smoother startup, suitable for environments that are sensitive to noise or focus on energy conservation
• If your rolling shutter door is installed in residential, hotel, hospital, etc., it is recommended to choose DC DC motors; if it is in industrial places such as factories, warehouses, etc., AC AC motors are a more cost-effective choice
3. How to choose the motor model suitable for my rolling shutter door?
Mainly choose based on the weight of the rolling shutter door: 300KG and below choose DCK-300KG, 300-600KG choose DCK-600KG, and so on. If the door body width exceeds 4 meters or the usage frequency is high, it is recommended to choose a larger model to ensure stable operation and service life. You can also provide the size and material of the door body to our customer service, and we will recommend the most suitable model for you.
