Soft Start And Slow Stop Linear Actuator Modern Design Auto Gate Opener Solar Powered Swing Gate Motor for Outdoor Application

Soft Start And Slow Stop Solar Powered Swing Gate Motor

The OMKER DCK series solar flat door motor is an energy-saving and intelligent door control solution specifically designed for outdoor complex environments. It combines advanced linear drive technology with modern industrial design aesthetics. The product features an integrated super-strong aluminum alloy body structure, with the surface treated through multiple anti-corrosion processes, ensuring excellent weather resistance and durability. It offers two precise models, DCK28 and DCK28-DC, supporting flexible operation modes for single or double doors, and can perfectly fit various flat door bodies such as aluminum doors, iron gates, copper doors, and wooden doors, with a maximum width of 3 meters and a weight of 300KG.

Quantity:
Availability:





Inquire Add to Basket

Product Description

>> Introduction

The Swing gate opener operates in two different ways of Dual/Single gate running mode,During modern automatic door operators operation,soft start and soft stop.Emergency release key in case of power failure,modern design auto gate can be equipped with a wide range of accessories.

The product has super strong aluminum alloy material design, beautiful and durable. And a new transmission design, more quiet, more stable operation. One click remote control, can control the opening, closing or stop.

By adopting advanced linear drive technology, the opening and closing of the door is smooth without any shock, effectively reducing the shaking of the door body and mechanical wear, and significantly extending the service life of the motor and the door body. The operation process is quiet and smooth, and it will not cause noise interference to the surrounding environment.

Model No.	DCK28	DCK28-DC
Max.Gate Width (m)	2.5	3
Max.Gate Weight(kg)	250	300
Power supply(V/HZ)	AC120V/220V~240V 50/60HZ	AC120V/220V~240V 50/60HZ
Motor Voltage (VDC)	24VDC	24VDC
Motor Power(W)	80W	120W
Rated Current(A)	5	8
Motor Rotation(RPM)	2200	2200
Operation Temperature(°C）	-45℃~+65℃	-45℃~+65℃
Water-proof Class(lP）	54	54
Operation efficiency(%)	70	70
Gate Opener Weight(kg)	20	22

>> Function And Features

Convenient and adjustable

Built in adjustable auto-close (0-99 seconds)

Built in max. Motor running time (MRT) adjustable for multiple safety protection (1-50 seconds)

Can set automatic closing time, single door start function.

Simple operation

Digital display indicates the running situation and setting menu.

Reliable electromagnetism limit for easy adjustment.

With a new transmission design, the operation is more quiet and smooth. One click remote control, can control the opening, closing or stop.

Intelligent operation

Adjustable opening/closing interval between master and slave gate.

Stop/Reverse in case of obstruction during gate opening/closing.

With infrared beam protection, alarm light prompt opening and closing operation, power failure emergency clutch lock.

Versatility suitable for all product

Automatic gate openers,AC/DC, sliding gate opener, swing gate opener, automatic retractable folding gate opener.

Saving money

Can control multiple gates, more gates more cost effective, can add 50 mobile phones, no need to add the remote controls.

Easy installation

After download APP and WIFI been connected,and long range control can be realized by mobile phone .

>> FAQ

1. What should I know before ordering?

The width and weight of your gate door.

2. May I have samples for testing?

Yes, samples are available. The lead time will be 2-3 days for samples.

3. How to pay for samples, and how you delivery it?

Samples can be paid by Western union, PayPal, Alibaba. Delivery by DHL, UPS or TNT, if you want to know the cost of delivery, please offer your detailed address with post code.

4. Does installation require professional personnel?

Installation requires certain electrical knowledge and mechanical installation experience. It is recommended to have it done by professionals. We provide detailed installation instructions and video tutorials, as well as ongoing online technical support.
