>> Introduction
Product light weight, small, easy to install, durable and reliable performance.The motor with low noise, little vibration and small power consumption.It can drive the rolling shutter door to roll up or down to realize the function of automatically opening and closing the door.
Model | Power Source (V) | Rated Frequency (Hz) | Lifting Force (KG) | Output Torque (N.m) | Output Speed (r/min) | Lifting/Mass Raising Height | Rated Power (W) | Rated Current (A) | Short-team Ration (min) |
DCK-300KG-1P | 220 | 50 | 300 | 164 | 5 | 6.0 | 250 | 2.5 | 8 |
DCK-300KG-3P | 380 | 50 | 300 | 343 | 5 | 6.0 | 180 | 0.8 | 15 |
DCK-600KG-1P | 220 | 50 | 600 | 412 | 6 | 6.0 | 370 | 3.5 | 8 |
DCK-600KG-3P | 380 | 50 | 600 | 412 | 6 | 6.0 | 250 | 1.5 | 15 |
DCK-800KG-1P | 220 | 50 | 800 | 647 | 4.2 | 9.0 | 400 | 4.7 | 8 |
DCK-800KG-3P | 380 | 50 | 800 | 647 | 4.2 | 9.0 | 300 | 2.3 | 15 |
DCK-1000KG-3P | 380 | 50 | 1000 | 810 | 3.6 | 9.0 | 400 | 2.4 | 15 |
DCK-1300KG-3P | 380 | 50 | 1300 | 1050 | 4.2 | 13.0 | 600 | 3.5 | 15 |
DCK-1500KG-3P | 380 | 50 | 1500 | 1220 | 3.8 | 13.0 | 600 | 4.0 | 15 |
DCK-DC-500KG-1P | 220 | 50 | 500 | 490 | 4.8 | 6.0 | 200 | 12.0 | |
DCK-DC-600KG-1P | 220 | 50 | 600 | 588 | 4.8 | 6.0 | 250 | 12.0 |
>> Function And Features
>> FAQ
1.Whether the product is easy to install?
The rolling shutter motor left or right installation is ok.
2.What are the advantages compared with the same series of products?
AC roller door motor with elegant design, advanced structure and strong power.
3.Where the product can be used?
Widely used in commercial facades, garages, shopping malls, hospitals, factories and mining enterprises and other public places or residential.
