>> Introduction
Card type(alternative) | EM Card (IC card for options) |
Storage | 4000 users |
Operating voltage | DC12V ±10% |
Operating current | <100mA |
Card reading distance | 1~15CM |
Ambient temperature | 0℃~60℃ |
Relative humidity | 20%~80% |
Dimensions | 115×80×24mm |
Weight | 110g |
Multi‑Mode Access Options: Supports RFID card, PIN code, card + password combined verification to meet different access management needs.
Backlit Touch Panel: Sensitive touch keys with backlight for clear visibility and easy operation under low‑light or night‑time conditions.
Outdoor Weather‑resistant Housing: Robust outer shell adapts to rain, dust and varying ambient temperatures for external installation.
Standard Wiegand Output: Compatible with most gate opener controllers and access panels via WG26/WG34 interface.
Large User Storage: Stores a good number of user PINs and RFID cards for household or small‑commercial multi‑user scenarios.
Simple Configuration: Buzzer and LED indicator offer audio‑visual feedback for programming, entry and troubleshooting.
FAQ
Q1: What access methods does this keypad support? A1: It offers three working modes: RFID card only, PIN password only, and card plus password combined verification for your selection.
Q2: Is this keypad fit for outdoor installation? A2: Yes. Its weather‑resistant casing can handle rain and dust, suitable for wall‑mount installation beside external gate points.
Q3: Can it work with my existing automatic gate opener? A3: It provides standard Wiegand 26/34 output. It is compatible with gate controllers that accept Wiegand access signal input.
Q4: What power supply does this keypad require? A4: It runs on DC 12V power input, you can power it through your gate control board or separate DC power adapter.
Q5: Does it work at night? A5: Yes. The backlit touch panel lights up for easy input in darkness, with LED and buzzer for operation feedback.
Q6: Can I add or delete RFID cards and user passwords locally? A6: Sure. You can finish adding or removing user credentials by following the instruction manual without extra software.
